Auxiliary Reference Operation E.g.

Keypad Frequency Setting is Main Frequency and V1 Analog Voltage is Auxiliary

Frequency

• Main frequency: Keypad (operation frequency 30 Hz)

• Maximum frequency setting (dr.20): 400 Hz

• Auxiliary frequency setting (bA.01): V1[Display by percentage(%) or auxiliary

frequency (Hz) depending on the operation setting condition]

• Auxiliary reference gain setting (bA.03): 50%

• In.01-32: Factory default output

Example: an input voltage of 6V is supplied to V1, and the frequency corresponding to

10 V is 60 Hz. The table below shows the auxiliary frequency A as 36 Hz[=60 Hz X (6

V/10 V)] or 60%[= 100% X (6 V/10 V)].

Setting*

Calculating final command frequency

M[z]+(G[%]*A[Hz])

30 Hz(M)+(50%(G)x36 Hz(A))=48 Hz

M[Hz]*(G[%]*A[%])

30 Hz(M)x(50%(G)x60%(A))=9 Hz

M[Hz]/(G[%]*A[%])

30 Hz(M)/(50%(G)x60%(A))=100 Hz

M[Hz]+{M[Hz]*(G[%]*A[%])}

30 Hz(M)+{30[Hz]x(50%(G)x60%(A))}=39 Hz

M[Hz]+G[%]*2*(A[%]-50[%])[Hz]

30 Hz(M)+50%(G)x2x(60%(A)–50%)x60

Hz=36 Hz

M[HZ]*{G[%]*2*(A[%]-50[%])}

30 Hz(M)x{50%(G)x2x(60%(A)–50%)}=3 Hz

M[HZ]/{G[%]*2*(A[%]-50[%])}

30 Hz(M)/{50%(G)x2x(60%–50%)}=300 Hz

M[HZ]+M[HZ]*G[%]*2*(A[%]-

50[%])

30 Hz(M)+30 Hz(M)x50%(G)x2x(60%(A)–

50%)

=33 Hz

*M: Main frequency reference/ G: Auxiliary reference gain (%)/ A: Auxiliary

frequency reference (Hz or rpm) or gain (%)
