Trip Setting Details to Multi-Function Relay
Code and
Features
Description
OU.30 Trip Out
Mode
Fault trip relay operates based on the fault trip output settings.
Items
Bit On Status
Bit Off Status
Keypad
After selecting the multi-function relay to use as the trip output,
select 29 (Trip Mode) in OU.31, 33. If the trip occurs from the
inverter, the applicable multi-function relay will be activated.
Activation status of multi-function relay can be set up as below
depending on the trip type.
Configuration
Function
bit3
bit2
bit1

Operates when low voltage fault trips
occur

Operates when fault trips other than low
voltage occur

Operates when auto restart fails (Pr. 08–
09)
OU.31 Relay1
Set the Relay 1 output item.
OU.33 Relay 2
Set the Relay 2 output item.
OU.53 TripOut On
Dly, OU.54 TripOut
OffDly
If a trip occurs, multi-function relay 1 or multi-function relay 2 will be
activated after the time set in multi-function. Terminal is off with the
input initialized after the time delay set in OU.54.
5.29.3 Multi-Function Relay Terminal Delay Time Settings
Set On delay time and Off delay time specifically to adjust the multi-function relay
operation time of the terminal. The delay time set in OU.50–51 will be applied to both
Relay 1 and Relay 2 except for when the multi-function relay feature is under trip
mode.
Group
Code
Name
Setting
Setting
Range
Unit
OU
50
Multi-function output On
delay
0.00
0.00–
100.00
sec
51
Multi-function output Off
delay
0.00
0.00–
100.00
sec
52
Multi-function output
contact selection
00*
00–11
bit
