LSIS G100 User Manual

Comm.
Address
Parameter
Scale
Unit
Assigned Content by Bit
B3
Virtual DI 4 (CM.73)
B2
Virtual DI 3 (CM.72)
B1
Virtual DI 2 (CM.71)
B0
Virtual DI 1 (CM.70)
0h0386
Digital output control
(0: Off, 1: On)
-
-
BI5
Reserved
BI4
Reserved
BI3
Reserved
BI2
Reserved
BI1
Reserved
BI0
Reserved
B9
Reserved
B8
Reserved
B7
Reserved
B6
Reserved
B5
Reserved
B4
Reserved
B3
Reserved
B2
Reserved
B1
Relay 2 (0.4–7.5 kW, OU-33:
None)
B0
Relay 1 (0.4–7.5 kW, OU-31:
None)
0h0387
Reserved
-
-
Reserved
0h0388
PID reference
0.1
%
PID reference command
0h0389
PID feedback value
0.1
%
PID feedback value
0h038A
Motor rated current
0.1
A
-
0h038B
Motor rated voltage
1
V
-
0h038C–
0h038F
Reserved
-
-
Reserved
0h0390
Torque Ref
0.1
%
Torque command
0h0391
Fwd Pos Torque Limit
0.1
%
Forward motoring torque limit
0h0392
Fwd Neg Torque Limit
0.1
%
Positive-direction regeneration torque
limit
0h0393
Rev Pos Torque Limit
0.1
%
Reverse motoring torque limit
0h0394
Rev Neg Torque Limit
0.1
%
Negative-direction regeneration torque
limit
0h0395
Torque Bias
0.1
%
Torque bias
Note
A frequency set via communication using the common area frequency address (0h0380,
0h0005) is not saved even when used with the parameter save function. To save a
changed frequency to use after a power cycle, follow these steps:
