LSIS G100 User Manual

Basic Tasks
Use Example
Ref.
For automatic start-up configuration to work, the
operation command terminals at the terminal block
must be turned on.
Acc/Dec Time Based
on Maximum
Frequency
Configures the acceleration and deceleration
times for a motor based on a defined maximum
frequency.
p.78
Acc/Dec Time Based
on Operation
Frequency
Configures acceleration and deceleration times for
a motor based on a defined frequency reference.
p.79
Multi-step Acc/Dec
Time Configuration
Configures multi-stage acceleration and
deceleration times for a motor based on defined
parameters for the multi-function terminals.
p.80
Acc/Dec time switch
frequency
Enables modification of acceleration and
deceleration gradients without configuring the
multi-functional terminals.
p.82
Acc/Dec pattern
configuration
Enables modification of the acceleration and
deceleration gradient patterns. Basic patterns to
choose from include linear and S-curve patterns.
p.83
Acc/Dec stop command
configuration
Stops the current acceleration or deceleration and
controls motor operation at a constant speed.
Multi-function terminals must be configured for this
command.
p.85
Linear V/F pattern
operation
Used for loads that require constant torque
regardless of the frequency.
p.85
Square reduction V/F
pattern operation
Configures the inverter to run the motor at a
square reduction V/F pattern. Fans and pumps are
appropriate loads for square reduction V/F
operation.
p.86
User V/F pattern
Operation
Enables the user to set the parameter according
to the V/F pattern and the load characteristics of
the motor.
p.87
manual torque boost
Manual configuration of the inverter to produce a
momentary torque boost. This configuration is for
loads that require a large amount of starting
torque, such as elevators or lifts.
p.90
Auto torque boost
Automatically adjusts the torque or is used when a
large amount of starting torque is required.
p.91
Motor output voltage
adjustment
Adjusts the output voltage to the motor when the
power supply to the inverter differs from the
motor’s rated input voltage.
p.91
Accelerating start
Acceleration start is a general acceleration mode.
If there are no extra settings applied, the motor
accelerates directly to the frequency reference
when the command is input.
p.92
DC braking after start
Configures the inverter to perform DC braking
p.93
