Code and
Features
Descriptio
n
End
[Acceleration /
deceleration pat
t
ern configu
ration]
[Acceleration /
deceleration S-curv
e patt
ern con
f
iguration]
Note
The A
ctual Acc/Dec time duri
ng an S-curve appli
cation
Actual acc
eleration time =
user-configure
d acceleration time +
user-configured
acceleration t
ime x starting gradi
ent level/2 + user-c
onfigured accelerat
ion time x ending
gradient level/
2.
Actual dec
eleration t
ime = user-configure
d decelerat
i
on time +
user-configured
deceleration t
ime x starting gradi
ent level/2 + user-c
onfigured decelerati
on time x ending
gradient level/
2.
95
97
