NTP-034: System Turnup 363-206-285
Page 5 of 6 Issue 2, February 2000
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED. . . . . FOR DETAILS, GO TO
11. Make necessary VT1.5/STS-1 cross-connections for each node.
DLP-546A. Single OC-3 Ring Configuration
DLP-550B. Dual Ring Interworking (DRI) Configuration
DLP-557C. Single/Dual OC-3/FiberReach Configuration
DLP-558D. Stand Alone OC-3/FiberReach Configuration
DLP-559E. Single/Dual OC-3/OC-48 Configuration
DLP-560F. Single/Dual OC-3/OC-12 Configuration
12. Perform the appropriate end-to-end transmission test for circuit(s)
being put into service. For a circuit in a path-protected single
OC-3 ring network, use the sw-path-( ):address command
at both terminating nodes to switch the active path and repeat this
test on the other path.
DLP-510A. DS1 Single OC-3 Ring Test
DLP-554B. DS1 Dual Ring (DRI) Test
DLP-511C. DS3 Single OC-3 Ring Test
DLP-553D. S3 Dual Ring (DRI) Test
13. Use the rtrv-state-eqpt: command to determine the port
state of the EC-1 port of the circuit being established.
14.
NOTE:
If a port is in the nmon (n) state, the signal is not monitored
or alarmed. The port will not automatically go to the in
service (i) state when a signal is detected as it will in the
auto (a)state.Inthenmon state, the port must be returned
to the auto state, using the set-state-ec1: command,
to turn on monitoring of signal failures and before any circuit
packs associated with that port can be removed from the
equipment list by the upd command.
Use the set-state-ec1: command to set the port state of the
EC-1 port of the circuit being established.
DLP-546
DLP-550
DLP-557
DLP-558
DLP-559
DLP-560
DLP-510
DLP-554
DLP-511
DLP-553
