MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the PC, CAT, or Printer
Page 5-14
Connecting a Printer to the Control Unit
To make the connections at the printer, follow the steps below. See
Figure 5-4 on page 5-13
.
!At the printer location, either plug one end of a D6AP cord into a
2012D-50M transformer or follow the instructions in Step 9 above.
!Plug the other end of the D6AP cord into the lower jack on a 400B2
power adapter.
!Plug the 400B2 power adapter into the wall jack.
!Plug the 2012D-50M (or 2012D) transformer into the wall outlet for
the printer.
!Plug one end of a second D8W cord into the top jack on the second
400B2 power adapter.
!Plug the other end of the second D8W cord into the WALL jack on
the Z3A2 ADU.
!Connect the 25-pin male connector on the Z3A2 ADU to the 25-pin
female end on a second 355AF adapter.
!Plug one end of a third D8W cord into the second 355AF adapter.
!Plug the other end of the third D8W cord into the SMDR jack on the
back of the CAT.
! Plug one end of a fourth D8W cord into the PRINTER jack on the
back of the CAT.
! Plug the other end of the fourth D8W cord into a third 355A adapter.
! Slide the third 355A adapter into the serial port on the back of the
printer.
! Set the appropriate printer options for SMDR.
See “Setting Printer Options and DIP Switches” on page 5-21
for
instructions.
