MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Applications
Page 8-20
MERLIN MAIL
*
The number of incoming trunks and subscribers programmed for
Automated Attendant service and the number of busy-hour calls
determine how many MERLIN MAIL
*
Voice Messaging System jacks are
required for the user’s system. See Table 8–2.
Considerations
You cannot connect MERLIN MAIL
*
Voice Messaging System to a
system operating in Behind Switch mode.
MERLIN MAIL
*
Voice Messaging System is available in 2-port and
4-port configurations. Both models have four hours of message-storage
capacity.
You can use up to eight jacks on an 012 basic telephone module or up to
16 jacks on an 016 (T/R) basic telephone module for MERLIN MAIL
*
.
If you use all eight jacks on an 012 module for MERLIN MAIL
*
, you
cannot connect any other devices to the module. When using fewer than
eight jacks on the 012 module, you can use the remaining jacks for
tip/ring devices.
When a mailbox user receives voice mail messages, the Message LEDs
on his or her telephone are on, provided that a physical telephone has
been assigned to that mailbox.
* This application is no longer available for order.
Table 8-2. MERLIN MAIL Ports Required
Number of Jacks Required 2 4
Incoming Trunks 1 to 6 7 to 18
Number of Subscribers or Busy-Hour Calls 1 to 20 21 to 60
