Lucent Technologies MERLIN LEGEND Release 6.1 Installation

MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Applications
Page 8-21
MERLIN MAIL
*
Trunks to be answered by MERLIN MAIL
*
should be programmed for
reliable far-end disconnect.
Callers who dial from rotary telephones cannot use MERLIN MAIL
*
features.
The system may need more touch-tone receivers if:
■ Single-line telephone users do not get a dial tone
■ MERLIN MAIL
*
fails to transfer calls
■ Calls fail to ring or go to coverage prematurely
■ Message-waiting lights fail to light
MERLIN MAIL
*
and Lucent Technologies Attendant
*
should not be used
on the same system.
Programming of MERLIN MAIL is done through a touch-tone interface.
MERLIN MAIL
*
has an EIA-232-D serial port and an external modem to
support remote diagnostics.
You cannot use the first four logical IDs on a 008 OPT module to
physically connect telephone equipment; however, you can use the
extension numbers of these logical IDs for phantom extensions.
Additional touch-tone receivers (TTRs) may be needed for the 012 or
016 (T/R) module to handle a large number of voice connections.
The MERLIN MAIL
†
unit can be desk- or wall-mounted and should be
placed in an area with low humidity and proper ventilation.
Follow the power and ground procedures for T/R telephones that require
auxiliary power.
* These applications are no longer available for order.
† These applications are no longer available for order.
