LUMAT LB 9507 - Measurements with Master Curve

LB 9507 Chapter 7: Quantitative Measurements (LIA...)
7-25
7.5.2 Measurements with Master Curve
The measurement procedure using a master curve defined in the
protocol is analogous to the measurement type described above.
The two calibrators are measured instead of the standards, and
the program then works with the predefined master curve using
this data. Only the differences are described below:
L1
READY
MEASURE PROTOCOL -OTHERS-
Select <MEASURE >.
L50
SELECT TYPE OF MEASUREMENT
PROTOCOLS DIRECT ENTRY RATEMETER
Select <PROTOCOLS> to open a stored protocol. Then select a
protocol with a master curve.
L51 to L57 are the same as with a standard series.
L58a
LOW CAL TUBE # 1
INSERT TUBE ...
Position the tube containing the low calibrator and press the
<start> button.
BACKGROUND MEASUREMENT ... INJECTION ...
MEASUREMENT...
L58b
SAMPLE-RLU 46
REMOVE TUBE
After you have removed the tubes you are prompted to:
