2. Design of Lumat LB 9507
This chapter describes the various components of Lumat
LB 9507.
Front view
1 Keyboard
2 Display
3 Thermal printer
4 Paper advance button
5 Reagent supply bottle (optional)
6 Injector line (optional)
7 Injector pumps (optional)
8 Sample holder cap (keeps out dust)
9 Measurement chamber with sample holder
10 <start> button
23 45678
1910
Fig. 2-1: Lumat LB 9507 (front view)
