Chapter 2: Design of the Lumat LB 9507
2-2
Inside view
Main switch; fuse holder Contrast for printer Host I/O HV; amplifier Air filter Injector pumps
Combi element and display RS 232 and analyzer
Power supply CPU Auxiliary board Stepper motor Tube detector Measurement chamber
for turning the
tube transport rotor
Fig. 2-2: Inside view of Lumat
Do not open the instrument!
The Lumat LB 9507 must only be opened by service
technicians authorised by Berthold Technologies!
Injector lines
Photomultiplier
Injector head
