LB 9507 Chapter 5: Raw Data Measurements

5-11

5.4 Performing Raw Data Measurements

There are two ways of performing a raw data measurement:

1. You can use a protocol which has already been created and

stored. To do this, select the option <PROTOCOLS> in the

<MEASURE> menu.

2. Alternatively, enter the parameters for the measurement you

want to run. To do this, select the option <DIRECT ENTRY>

in the <MEASURE> menu and enter the measurement

parameters. These are the parameters listed in displays R5

to R19. Then start the measurement.

Measurement with

stored protocol

READY

MEASURE PROTOCOL -OTHERS-

Select <MEASURE>.

R21

SELECT TYPE OF MEASUREMENT ?

PROTOCOLS DIRECT ENTRY RATEMETER

Select <PROTOCOLS> to open a stored protocol.

Select <DIRECT ENTRY> to activate the input sequence for the

measurement parameters of a direct measurement.

R22

ENTER PROTOCOL NO. 6

PRINT LIST

Enter the number of the protocol required and press <enter>.

You can print out the list of stored protocols including number and

name by pressing the button below <PRINT LIST>.
