LB 9507 Chapter 8: T-Uptake/FTI-Measurements
8-15
T46
REMOVE TUBE...
Remove the tube from the sample holder if there is one. This
display appears if there is a tube in the sample holder. So, if a
tube already is in the correct position before you start
measurement, you will have to lift the tube briefly. You will then
see:
T47
STD#1 REPL#1 TUBE#1
INSERT TUBE...
Load the 1st standard tube.
T47a
STD # 1 REPL. # 1 TUBE # 1
START
Press the <Start> button. The measurement procedure defined in
the protocol now runs:
T48
MEASURING BACKGROUND...
Background measurement is performed, assuming you specified
it in the protocol.
T49
BACKGROUND TOO HIGH !
This display only appears when the background threshold you
have defined in the protocol is exceeded. If this happens the
printout of measurement values is flagged BKG.
The steps which the instrument goes through are displayed and
the measurement parameters from the active protocol are printed
out at the same time.
