LB 9507 Chapter 1: System Description
1-7
Chart of measurement procedure
Display User action Instrument action
1 SAMPLE 1 TUBE 1
INSERT TUBE... Load the 1st tube
2 SAMPLE 1 TUBE 1
START
Press <start> button
Rotor turns the 1st tube
in measurement position
3 MEASURING... Measuring tube 1
4 MEASUREMENT (RLU) 133 Display results
5 SAMPLE 2 TUBE 2
INSERT TUBE... Load the 2nd tube
6 SAMPLE 2 TUBE 2
START
Press <start> button
Rotor turns the 2nd tube
in measurement position
7 MEASURING... Measuring tube 2
8 MEASUREMENT (RLU) 137
REMOVE TUBE Remove the 1st tube Displays results
9 SAMPLE 3 TUBE 3
INSERT TUBE... Load the 3rd tube
10 SAMPLE 3 TUBE 3
START
Press <start> button
Rotor turns the 3rd tube
in measurement position
Pressing the <exit> button finishes measurement.
