214713 203 Revision A
Chapter 11: Reference
11.1 Opening Cutterbar Doors
DANGER
To avoid bodily injury or death from unexpected startup of machine, always stop engine and remove key
from ignition before leaving operator’s seat for any reason.
1. Center mower beneath hitch to open both doors.
Figure 11.1: R113 Pull-Type Disc Mower
2. Lift door at front to open.
