MacDon R113 - Removing Disc Mower from Shipping Pallet (no Transport Installed)

214713 116 Revision A
5.9 Removing Disc Mower from Shipping Pallet (No Transport
Installed)
NOTE:
If you have the Road Friendly Transport
™
system, refer to 5.10 Removing Disc Mower from Shipping Pallet
(Transport Installed), page 117.
1016476
A
A
C
B
Figure 5.56: Strapping
1. Cut strapping (B) securing cutterbar to pallet (C).
2. Place forks from lifting device at openings (A). Spread
them as far apart as possible to spread the load out.
3. Lift disc mower high enough that the pallet can be
removed.
1016477
A
Figure 5.57: Removing Shipping Pallet
4. Use a chain or forklift to remove shipping pallet (A) from
underneath the disc mower.
5. Lower the disc mower to the ground.
