5.5 Priming the Hitch Swing Cylinder
NOTE:
The hitch swing cylinder must be primed before it is connected to the rear arm link.
1023717
A
B
Figure 5.21: Remote Control
1. Move the transport switch on the remote control to the
lower position (B) and ensure that light (A) is
illuminated. The hitch swing circuit will now be active.
