214713 121 Revision A
6.2 Lubrication Points
Unless otherwise specified, use high-temperature, extreme-pressure (EP2) performance grease with 1% max
molybdenum disulphide (NLGI grade 2) lithium base.
Figure 6.5: Lubrication Points
1026364
A
B
C
D
E
F
B - Hitch Pivot C - Hitch Swivel
E - Bearing, Roller Conditioner F - Bearing, Roller Conditioner
A - Bearing, Finger Conditioner
D - Idler Pivot
LUBRICATING THE DISC MOWER
