4-33
[10] WASHING WASHABLE FLOOR
• When setting the machine at an angle, use strong blocks to stabilize the machine and be
extremely careful when carrying out the operation.
• If the control levers are touched by mistake, the machine may suddenly move, and this may
lead to a serious accident. Always set the lock lever securely to the LOCK position before
standing up from the operator‟s seat.
While cleaning the cab floor, take care so that the connector, air conditioner main body and
filters may not be splashed with water.
With the washable floor, it is possible to flush out the dirt on the cab floor directly with water.
[METHOD OF WASHING]
1. Set the machine at an angle. For details, see “Method of Setting
Machine at Angle”.
2. Swing the upper structure slowly so that water drain holes (1) in
the cab floor are at a low position.
3. Set the lock lever to the LOCK position (L) and stop the engine.
4. Remove the floor mat.
5. Flush out the dirt on the floor directly with water through water drain hole (1).
6. After completing the washing operation, install the floor mat.
