136
Mahr GmbH • Digimar 817 CLM
Adjust the nomimal values
3. Create new program
4. Change existing program
5. Print out current program
1. <-_______
2. Change program head
3. Change program form
4. Change record head
5. Save changes
Please refer to chapter 7.3.3 Create program steps
Step : 1 Charact :
Group n
o
: 0 Group : Main group
Function : xxxx Comment :
Nom. val. : 20.012 Channel : 0
Upp. all. : 0.000 UCL X : 0.000
Low. all. : 0.000 LCL X : 0.000
Paret. UT : 1.000 LCL RIS : 0.000
Paret. LT : 1.000 UCL RIS : 0.000
Step : 1 Charact :
Group n
o
: 0 Group : Main group
Function : xxxx Comment :
Nom. val. : 20.000 Channel : 0
Upp. all. : 0.000 UCL X : 0.000
Low. all. : 0.000 LCL X : 0.000
Paret. UT : 1.000 LCL RIS : 0.000
Paret. LT : 1.000 UCL RIS : 0.000
Enter the „nominal values“ of the gage blocks. Skip
with the arrow key to the value 20.012 and adjust.
Confirm with the „ON/OFF“ key, adjust all the nominal
values, after the last characteristic press the „Abort“
key, to exit this menu and to save the adjusted values.
ON
OFF
1. <-_______
2. Change program head
3. Change program form
4. Change record head
5. Save changes
Use the following keys to move within the input
box:
+ / - to scroll between program steps
Left and right arrow keys to move within the
input box
Tab function - to skip between input boxes
Skip to the start (Step__ 1)
Switch between upper and lower case
