Man B&W S50ME-B9.3-TII User Manual

PCD
L
C
A
IL
G
Dia 1
Dia 2
W
IW
D
B
F
N x diameter (O)
N x diameter (O)
D
B
A
G
C
F
IL
L
W
IW
N x diameter (O)
Counterflanges, Connection D
MAN Type TCA44-99
Type TCA series – Rectangular type
TC L W IL IW A B C D E F G N O
TCA44 1,054 444 949 340 1,001 312 826 408 1,012 104 118 24 ø13.5
TCA55 1,206 516 1,080 390 1,143 360 1,000 472 1,155 120 125 26 ø17.5
TCA66 1,433 613 1,283 463 1,358 420 1,200 560 1,373 140 150 26 ø17.5
TCA77 1,694 720 1,524 550 1,612 480 1,440 664 1,628 160 160 28 ø22
TCA88 2,012 855 1,810 653 1,914 570 1,710 788 1,934 190 190 28 ø22
TCA99 2,207 938 1,985 717 2,100 624 1,872 866 2,120 208 208 28 ø22
IL
L
A
C
E
G
I
F
IW
W
F
K
J
H
D
B
N x diameter (O)
Type TCA series
TC L W IL IW A B C D E F G H I J K N O
TCA33 802 492 690 400 755 448 712 427 568 100 417 387 260 329 254 24 ø13,5
MAN Type TCA33
MAN B&W 5.10
Page 1 of 3
MAN Diesel
MAN B&W MC/MC-C, ME/ME-C/ME-B/-GI engines 198 66 70-0.6
501 29 91-0.13.0a
178 63 96-2.0
