MAN B&W 4.01
Page 6 of 6
MAN Diesel
198 43 000.3MAN B&W 98-50 TII engines
Yard deliveries are:
1. Cooling water pipes to the builton lubricating
oil cooling system, including the valves.
2. Electrical power supply to the lubricating oil
standby pump built on to the RCF unit.
3. Wiring between the generator and the operator
control panel in the switchboard.
4. An external permanent lubricating oil fillingup
connection can be established in connection
with the RCF unit. The system is shown in Fig.
4.03.03 ‘Lubricating oil system for RCF gear’.
The dosage tank and the pertaining piping
are to be delivered by the yard. The size of the
dosage tank is stated in the table for RCF gear
in ‘Necessary capacities for PTO/RCF’ (Fig.
4.03.02).
The necessary preparations to be made on
the engine are specified in Figs. 4.03.01a and
4.03.01b.
Additional capacities required for BW III/RCF
The capacities stated in the ‘List of capacities’ for
the main engine in question are to be increased
by the additional capacities for the crankshaft
gear and the RCF gear stated in Fig. 4.03.02.
Extent of delivery for BW III/RCF units
The delivery comprises a complete unit ready to
be builton to the main engine. Fig. 4.02.01 shows
the required space and the standard electrical
output range on the generator terminals.
Standard sizes of the crankshaft gears and the
RCF units are designed for: 700, 1200, 1800 and
2600 kW, while the generator sizes of make A. van
Kaick are:
Type
DSG
440 V
1800
kVA
60 Hz
r/min
kW
380 V
1500
kVA
50 Hz
r/min
kW
62 M24 707 566 627 501
62 L14 855 684 761 609
62 L24 1,056 845 940 752
74 M14 1,271 1,017 1,137 909
74 M24 1,432 1,146 1,280 1,024
74 L14 1,651 1,321 1,468 1,174
74 L24 1,924 1,539 1,709 1,368
86 K14 1,942 1,554 1,844 1,475
86 M14 2,345 1,876 2,148 1,718
86 L24 2,792 2,234 2,542 2,033
99 K14 3,222 2,578 2,989 2,391
In the event that a larger generator is required,
please contact MAN Diesel & Turbo.
If a main engine speed other than the nominal is
required as a basis for the PTO operation, it must
be taken into consideration when determining the
ratio of the crankshaft gear. However, it has no
influence on the space required for the gears and
the generator.
The PTO can be operated as a motor (PTI) as well
as a generator by making some minor modifica-
tions.
178 34 893.1
