MAN B&W 15.02
Page 2 of 2
MAN Diesel
198 79 164.0MAN B&W S50MC6, S50MC-C, S50MEC7/8/-GI, S50ME-B8/9,
G50/45/40ME-B9, S46MC-C7/8, S46ME-B8, S42MC7, S40ME-B9,
S40MC-C9, S35MC-C9, S35MC7, L35MC6, S35ME-B9, S30ME-B9,
S26MC6
Cleaning Systems
Fig. 15.02.02: MAN TCA turbocharger, water washing of compressor side, option: 4 59 145
178 61 90-0.0
178 61 87-7.0.0
Compressor cleaning
MAN Diesel TCA turbocharger
To bedplate drain, AE
AP
Drain
Dry cleaning turbine side
PI 8803
ABB Turbocharger
Compressor cleaning
To bedplate drain, AE
Fig. 15.02.03: Soft blast cleaning of turbine side and water washing of compressor side for ABB turbochargers
