Man B&W S50ME-B9.3-TII User Manual

MAN B&W 7.03
Page 1 of 1
MAN Diesel
MAN B&W S50ME-B, S46ME-B, S40ME-B, S35ME-B, S30ME-B 198 50 52-4.3
Fuel Oil Pipes and Drain Pipes
The letters refer to list of ‘Counterflanges’
The item No. refer to ‘Guidance values automation’
508 28 99-5.2.1
Fig. 7.03.01: Fuel oil and drain pipes
Fuel valves
Fore
Aft
Leakage alarm
Leakage,
high press.
pipes
Baseplate
Counterpressure valve
Mixed oil drain
Fuel oil inlet
Fuel valves
Pressure booster
Fuel oil outlet
(umbrella)
Drain for fuel oil
Fuel oil
return pipe
AF AE
F
X
To sludge tank
To sludge tank
Clean HFO return
to HFO service tank
or settling tank
Cyl. 1
Baseplate
drain alarm
AE
LS 4112 AH
PI 8001
TI 8005
TE 8005 I
PT 8001 I AL
LS 8006 AH
