List of Capacities for 5S50ME-B9.3-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA55-24
1 x A165-L37
1 x MET53MB
1 x TCA55-24
1 x A265-L
1 x MET53MB
1 x TCA55-24
1 x A165-L37
1 x MET53MB
1 x TCA55-24
1 x A265-L
1 x MET53MB
Pumps
Fuel oil circulation m³/h 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2 4.2
Fuel oil supply m³/h 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4
Jacket cooling m³/h 80 80 80 80 80 80 80 80 80 80 80 80
Seawater cooling * m³/h 272 273 276 277 278 281 267 267 268 272 272 273
Main lubrication oil * m³/h 190 190 190 190 190 190 190 190 190 190 190 190
Central cooling * m³/h - - - - - - 210 212 214 214 215 218
Scavenge air cooler(s)
Heat diss. app. kW 3,310 3,310 3,310 3,420 3,420 3,420 3,290 3,290 3,290 3,400 3,400 3,400
Central water flow m³/h ------ 118 118 118 121 121 121
Seawater flow m³/h 162 162 162 167 167 167 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 750 760 780 750 760 780 750 760 780 750 760 780
Lube oil flow * m³/h 190 188 189 190 188 189 190 188 189 190 188 189
Central water flow m³/h ------ 92 93 96 92 93 96
Seawater flow m³/h 110 111 114 110 111 114 - - - - - -
Jacket water cooler
Heat diss. app. kW 1,410 1,410 1,410 1,410 1,410 1,410 1,410 1,410 1,410 1,410 1,410 1,410
Jacket water flow m³/h 85 85 85 85 85 85 81 81 81 81 81 81
Central water flow m³/h ------ 92 93 96 92 93 96
Seawater flow m³/h 110 111 114 110 111 114 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 5,450 5,460 5,480 5,560 5,570 5,590
Central water flow m³/h ------ 210 212 214 214 215 218
Seawater flow m³/h - - - - - - 267 267 268 272 272 273
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0
Compressor cap. m³ 300 300 300 300 300 300 300 300 300 300 300 300
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5
Compressor cap. m³ 150 150 150 150 150 150 150 150 150 150 150 150
Other values
Fuel oil heater kW 70 70 70 70 70 70 70 70 70 70 70 70
Exh. gas temp. ** °C 255 255 255 235 235 235 255 255 255 235 235 235
Exh. gas amount ** kg/h 63,804 63,804 63,804 67,355 67,355 67,355 63,804 63,804 63,804 67,355 67,355 67,355
Air consumption ** kg/s 17.3 17.3 17.3 18.3 18.3 18.3 17.3 17.3 17.3 18.3 18.3 18.3
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01e: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
