MAN Diesel
MAN B&W ME-B engines 198 51 84-2.3
Engine Control System Layout
178 55 62-2.0
On Bridge
In Engine Control Room
In Engine Room/On Engine
Bridge Panel
ESC
PUMP 1
M
PUMP 2
M
HPS
ECR PANEL
CRANKSHAFT
POSITION
SENSORS  CPS
CCU 1
MOP A
ELFI
ELFI
ALSALS
Pressure
Booster
Pressure
Booster
HCU (cyl m+n)
ELFI
ELFI
ALSALS
Pressure
Booster
Pressure
Booster
HCU (cyl 1+2)
MOP B
MPC  Multi Purpose Controller
EICU  Engine Interface Control Unit (MPC)
CCU  Cylinder Control Unit (MPC)
MOP  Main Operating Panel
HPS  Hydraulic Power Supply
CPS  Crankshaft Position Sensors
ESC  Engine Side Console
ALS  Alpha Lubricator System
 Actuator
EICU
CCU ½n
Fig. 16.01.01: Engine Control System Layout
