MAN B&W 4.03
Page 5 of 6
MAN Diesel
198 43 156.3MAN B&W 98 → 50MC/MC-C/ME/ME-C/ME-B/-GI
Stator shell
Stuffing box
Crankshaft
Air cooler
Main bearing No. 1
Pole wheel
Standard engine, with direct
mounted generator (DMG/CFE)
Support
bearing
Air cooler
Pole wheel
Stator shell
Stuffing box
Crankshaft
Main bearing No. 1
Standard engine, with direct mounted
generator and tuning wheel
Tuning wheel
Fig. 4.03.05: Standard engine, with direct mounted generator and tuning wheel
178 06 637.1
Mains, constant frequency
Excitation converter
Synchronous
condenser
G
Diesel engine
DMG
Static converter
Smoothing reactor
Fig. 4.03.06: Diagram of DMG/CFE with static converter
178 56 553.1
