External Forces and Moments, S50ME-B9.3 Layout point L
1
a) 1st order moments are, as standard, balanced so as to obtain equal values for horizontal and vertical moments for
all cylinder numbers.
Ta ble 17.07.01
No of cylinder : 5 6 7 8 9
Firing type : 1-4-3-2-5 1-5-3-4-2-6 1-7-2-5-4-3-6 1-8-3-4-7-2-5-6
1-6-7-3-5-8-2-
4-9
External forces [kN] :
1. Order : Horizontal 0 0 0 0 0
1. Order : Vertical 0 0 0 0 0
2. Order : Vertical 0 0 0 0 0
4. Order : Vertical 0 0 0 0 0
6. Order : Vertical 0 10 0 0 0
External moments [kNm] :
1. Order : Horizontal a) 102 0 61 203 209
1. Order : Vertical a) 102 0 61 203 209
2. Order : Vertical 1,210 842 244 0 275
4. Order : Vertical 8 60 172 70 87
6. Order : Vertical 1 0 0 0 22
Guide force H-moments in [kNm] :
1 x No. of cyl. 952 758 594 442 302
2 x No. of cyl. 103 30 11 17 27
3 x No. of cyl. - - - - -
Guide force X-moments in [kNm] :
1. Order : 85 0 50 169 174
2. Order : 216 150 44 0 49
3. Order : 176 318 348 446 551
4. Order : 37 284 806 328 408
5. Order : 0 0 76 950 375
6. Order : 22 0 13 0 778
7. Order : 167 0 0 30 38
8. Order : 109 76 6 0 20
9. Order : 6 119 13 12 0
10. Order : 0 28 80 0 8
11. Order : 2 0 43 56 5
12. Order : 10 0 2 8 31
13. Order : 4 0 0 11 4
14. Order : 0 2 0 0 3
15. Order : 0 7 0 1 12
16. Order : 0 3 1 0 1
