List of Capacities for 6S50ME-B9.3-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA55-26
1 x A170-L37
1 x MET53MB
1 x TCA66-24
1 x A170-L37
1 x MET60MB
1 x TCA55-26
1 x A170-L37
1 x MET53MB
1 x TCA66-24
1 x A170-L37
1 x MET60MB
Pumps
Fuel oil circulation m³/h 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
Fuel oil supply m³/h 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
Jacket cooling m³/h 97 97 97 97 97 97 97 97 97 97 97 97
Seawater cooling * m³/h 323 327 328 332 333 337 319 320 320 326 327 328
Main lubrication oil * m³/h 220 220 220 220 220 220 220 220 220 220 220 220
Central cooling * m³/h - - - - - - 250 253 254 257 258 261
Scavenge air cooler(s)
Heat diss. app. kW 3,970 3,970 3,970 4,100 4,100 4,100 3,950 3,950 3,950 4,080 4,080 4,080
Central water flow m³/h ------ 141 141 141 146 146 146
Seawater flow m³/h 194 194 194 200 200 200 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 880 910 910 900 910 930 880 910 910 900 910 930
Lube oil flow * m³/h 218 217 217 220 217 218 218 217 217 220 217 218
Central water flow m³/h ------ 109 112 112 110 112 114
Seawater flow m³/h 129 133 134 131 133 136 - - - - - -
Jacket water cooler
Heat diss. app. kW 1,690 1,690 1,690 1,690 1,690 1,690 1,690 1,690 1,690 1,690 1,690 1,690
Jacket water flow m³/h 102 102 102 102 102 102 97 97 97 97 97 97
Central water flow m³/h ------ 109 112 112 110 112 114
Seawater flow m³/h 129 133 134 131 133 136 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 6,520 6,550 6,550 6,670 6,680 6,700
Central water flow m³/h ------ 250 253 254 257 258 261
Seawater flow m³/h - - - - - - 319 320 320 326 327 328
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0
Compressor cap. m³ 300 300 300 300 300 300 300 300 300 300 300 300
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5 2 x 2.5
Compressor cap. m³ 150 150 150 150 150 150 150 150 150 150 150 150
Other values
Fuel oil heater kW 84 84 84 84 84 84 84 84 84 84 84 84
Exh. gas temp. ** °C 255 255 255 235 235 235 255 255 255 235 235 235
Exh. gas amount ** kg/h 76,565 76,565 76,565 80,826 80,826 80,826 76,565 76,565 76,565 80,826 80,826 80,826
Air consumption ** kg/s 20.8 20.8 20.8 22.0 22.0 22.0 20.8 20.8 20.8 22.0 22.0 22.0
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01f: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
