List of Capacities for 8S50ME-B9.3-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA66-26
1 x A175-L35
1 x MET66MB
1 x TCA66-26
1 x A175-L37
1 x MET66MB
1 x TCA66-26
1 x A175-L35
1 x MET66MB
1 x TCA66-26
1 x A175-L37
1 x MET66MB
Pumps
Fuel oil circulation m³/h 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7 6.7
Fuel oil supply m³/h 3.9 3.9 3.9 3.8 3.8 3.8 3.9 3.9 3.9 3.8 3.8 3.8
Jacket cooling m³/h 129 129 129 129 129 129 129 129 129 129 129 129
Seawater cooling * m³/h 432 437 440 441 446 449 425 427 428 434 436 436
Main lubrication oil * m³/h 280 270 280 280 270 280 280 270 280 280 270 280
Central cooling * m³/h - - - - - - 335 339 342 341 346 348
Scavenge air cooler(s)
Heat diss. app. kW 5,290 5,290 5,290 5,470 5,470 5,470 5,270 5,270 5,270 5,440 5,440 5,440
Central water flow m³/h ------ 188 188 188 194 194 194
Seawater flow m³/h 259 259 259 267 267 267 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 1,180 1,220 1,240 1,180 1,220 1,240 1,180 1,220 1,240 1,180 1,220 1,240
Lube oil flow * m³/h 275 273 275 275 273 275 275 273 275 275 273 275
Central water flow m³/h ------ 146 150 152 146 150 152
Seawater flow m³/h 173 179 182 173 179 182 - - - - - -
Jacket water cooler
Heat diss. app. kW 2,240 2,240 2,240 2,240 2,240 2,240 2,250 2,250 2,250 2,250 2,250 2,250
Jacket water flow m³/h 135 135 135 135 135 135 129 129 129 129 129 129
Central water flow m³/h ------ 146 150 152 146 150 152
Seawater flow m³/h 173 179 182 173 179 182 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 8,700 8,740 8,760 8,870 8,910 8,930
Central water flow m³/h ------ 335 339 342 341 346 348
Seawater flow m³/h - - - - - - 425 427 428 434 436 436
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0 2 x 5.0
Compressor cap. m³ 300 300 300 300 300 300 300 300 300 300 300 300
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0 2 x 3.0
Compressor cap. m³ 180 180 180 180 180 180 180 180 180 180 180 180
Other values
Fuel oil heater kW 112 112 112 112 112 112 112 112 112 112 112 112
Exh. gas temp. ** °C 255 255 255 235 235 235 255 255 255 235 235 235
Exh. gas amount ** kg/h 102,087 102,087 102,087 107,768 107,768 107,768 102,087 102,087 102,087 107,768 107,768 107,768
Air consumption ** kg/s 27.7 27.7 27.7 29.3 29.3 29.3 27.7 27.7 27.7 29.3 29.3 29.3
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01h: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
