Man B&W S50ME-B9.3-TII - Forces and Moments at Turbocharger

MAN B&W 15.06
Page 1 of 3
MAN Diesel
199 00 55-0.0MAN B&W S50ME-B9
Forces and Moments at Turbocharger
Turbocharger(s) located on exhaust side
DA
DB
DB
DC
Fig. 15.06.01a: Vectors of thermal expansion at the turbocharger exhaust gas outlet flange, TC on exhaust side
078 87 11-1.0.0b
Table 15.06.02a: Max. expected movements of the exhaust gas flange resulting from thermal expansion, TC on exhaust side
No. of cylinders 5-9 5 6 7 8 9
Turbocharger DA DB DC DC DC DC DC
Make Type mm mm mm mm mm mm mm
MAN
TCA44
Available on request
TCA55
TCA66
TCA77
ABB
A265
A170 / A270
A175 / A275
A180
MHI
MET42
MET48
MET53
MET60
MET66
MET71
DA: Max. movement of the turbocharger flange in the vertical direction
DB: Max. movement of the turbocharger flange in the transversal direction
DC: Max. movement of the turbocharger flange in the longitudinal direction
