MAN B&W 5.16
Page 3 of 3
MAN Diesel
MAN B&W ME-B/-GI engines 198 82 74-5.0
188 04 91-4.4.0
Fig. 5.16.03 The EICU cabinet unit for the ME-B Engine Control System
Printer
Network printer, ink colour printer
EICU Cabinet
Engine interface control cabinet for ME-ECS for
installation in ECR (recommended) or ER
188 23 16-6.1.0
