MAN B&W MC/MC-C, ME/MEC/ME-B/GI engines 198 45 875.13
Cables
Detector head
Junction box
XS 8813 AH Y
Driving air connection
Exhaust air connection to crank space
Siphonblock
XS 8813 AH Y
Fig. 18.06.01a: Oil mist detector wiring on engine, example based on type Graviner MK6 from Kidde Fire Protection,
option: 4 75 161
178 49 809.3
Fig. 18.06.01b: Oil mist detector pipes on engine, type Visatron VN215/93 from Schaller Automation, option: 4 75 163
178 49 810.3
