SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-14
Published 06-24-16, Control # 241-01
DANGER
Falling Jack Hazard!
Avoid serious injury. Fully retract the jack before unlocking
from stored position.
Failure to do so may cause the jack to rotate down at
uncontrolled speed with considerable force.
Pin the Strut Here
for Storage
Jack Pad
OPERATING
POSITION
Rotate the Lever to
Engage and Disengage
Rotate Jack to Desired Position
for Operation or Storage
STORED
POSITION
Pin Strut Here for
Storage
Jack Pad
Disengage the Stop Block for
the Operating Position
or
Engage the Stop Block for the
Stored Position
Pin the Strut Here
for Operation
Pin Strut Here for
Operation
View B
Rear Jack
(typical 2 places)
OPERATING POSITION
Rotate the Jack to Desired
Position for Operation or
Storage
Rotate Lever to Engage
and Disengage Pin
View A
Front Jack
(typical two places)
STORED
POSITION
Swing the Jack to Desired Position
for Operation or Storage
Rotate Jack to Desired Position
for Operation or Storage
A1047
JACK POSITIONS
FIGURE 4-8
