2250 OPERATOR MANUAL SETUP AND INSTALLATION
See Figure 4-18 for the remaining steps.
NOTE: The circled numbers in Figure 4-18
correspond to
the numbers of the following steps.
7. Swing the crawler by hand, as required, so the drive
shaft is at the rear of the carbody, and the drive shaft
flanges are as shown in View B.
8. Fully disengage the crawler frame pins with the control
on the setup remote control.
9. Lower the crawler and raise the boom. Swing the boom
as needed to engage the top connecting holes in the
crawler frame with the top connecting pins in the
carbody (see View D).
10. After the top holes engage the pins, continue to lower
the crawler until the chains are slack. The bottom
connecting holes will be in line with the crawler frame
pins.
11. Engage the crawler frame pins and install the retaining
pins (see View A).
12. Lift the crawler drive shaft off the supporting bracket (see
View B), extend the shaft, and align the holes in the drive
shaft flange (see View C).
13. Insert the flange screws and tighten them to 100 Nm
(74 ft-lb) (see View C).
14. Slide the drive shaft guard over the drive shaft (see
View E) and pin the guard to the carbody.
15. Unhook the handling chain assembly from the lugs on
the crawler frame.
DANGER
Rotating Drive Shaft Hazard!
The crawler drive shaft rotates at high speed. Death or
serious injury will occur if body parts or clothing come in
contact with a rotating drive shaft.
To prevent death or serious injury:
• Make sure the drive shaft is securely attached at both
ends.
• Make sure the guards are in place and securely
attached at both ends during operation.
• Do not attempt to service the drive shaft until the
crane has been parked and the engine stopped.
