SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-34
Published 06-24-16, Control # 241-01
Rear Jack in
“Wing” Position
(2 places)
P680a
View A
Method A
View C
First
Crawler
Installed
Trailer Carrying Second Crawler
Positioned on Opposite Side of Carbody
that First Crawler Was Installed On
View B
Method B
Swing 180° to
Install Second
Crawler
See View C
First Crawler Installed
and Lowered to Ground
Trailer Carrying Second
Crawler Positioned on Same
Side of Carbody as First
Crawler
A1048
A1048
FIGURE 4-19
