Reference Only
SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-126
Published 06-24-16, Control # 241-01
Upper
Boom
Point
Long
Reach
Boom
Dead End
for Even Parts
Dead End for
Odd Parts
Load
Block
Lower
Boom
Point
A483
7 PART
4 PART3 PART2 PART
6 PART
5 PART
Suggested Location of Weight
for Block-Up Limit Control
=
A712
Upper Boom Point
W
i
r
e
R
o
p
e
Gu
i
d
e
Lower
Boom
Point
Load
Block
Wire
Rope
Guide
Dead End
for 2 Parts
Load-
Sensing
Sheaves
Weight
Ball
FIGURE 4-71
STANDARD LIFTCRANE
#44 Long Reach Boom
