Reference Only
Manitowoc Published 06-24-16, Control # 241-01 4-129
2250 OPERATOR MANUAL SETUP AND INSTALLATION
4
FIGURE 4-73 continued
Wire Rope
Guide
Upper
Boom
Point
Lower
Boom Point
Dead End
for Even Parts
See
Figure 4-74
Weight
Ball
Dead End
for 2 Parts
Dead End
for Odd Parts
Load
Block
A483
Heavy
Lift Boom
Load-
Sensing
Sheaves
11 PART 12 PART 13 PART 14 PART
15 PART 16 PART
18 PART
17 PART
STANDARD LIFTCRANE
#44 or 44A Heavy Lift Boom
