1.6 Definition of direction references
16.08.2018
Maintenance manual 3 302 577 en 1 - 5
GMK7450
1.6 Definition of direction references
Basic rule Directions always depend on whether the carrier or the superstructure is
being operated.
On the carrier
The driver's cab is always at the front, which means that:
Forwards always means with drive
r's cab leading,
Backwards always means the
rear lights on the carrier are to the front.
On the superstructure
The main boom head is always at the front, which means that:
Switches and
buttons
For swi
tches and buttons, the terms at the bottom and at the top are used.
Regardless of the fitting position (vertical, horizontal, diagonal, transverse
or turned), the following always applies:
1: front 2: right
3: rear 4: left
1: front 2: right
3: rear 4:
left
At the bottom: press in at (1) – next to the symbol
At the top:
press in at (2) – opposite the symbol
