Spare parts required for maintenance
11.4 Spare parts for the superstructure
11 - 8 3 302 577 en Maintenance manual
GMK7450
16.08.2018
11.4 Spare parts for the superstructure
Assemblies and spare parts
Superstructure
GROVE-
Part number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Engine
Air
filter – main filter 04256761
1 item when the symbol lights up
Air filter – back-up filter 04256762
Oil filter 9414101679 1
Drain plug seal 03042029 1
Fuel system
Filter 1 04182148 1
Filter 2 04182157 1
Exhaust system with exhaust emission control
AdBlue/DEF filter 04182142 1
Hoists
Ga
sket 14 x 1
8 Cu DIN 7603 00117131 (2)
(if damaged)
Gasket 18 x 22 Cu DIN 7603 00117137 (4)
Gasket 14 x 18 Cu DIN 7603 00117131 2
Gasket 18 x 22 Cu DIN 7603 00117137 4
Gasket 26 x 31 Cu DIN 7603 00117147 4
Slewing gear
Ga
ske
t 10 x 1
4 Cu DIN 7603 00117125 (3) (if damaged)
Gasket 10 x 14 Cu DIN 7603 00117125 3
Gasket 14 x 20 Cu DIN 7603 00117132 3
Pump transfer case
Gasket A21 x 26
x 2 03043651 1 2
