Manitowoc GROVE GMK7450 - Lubricating the Locking of Turntable

Maintenance work on the superstructure
8.8 Slewing bearing
8 - 64 3 302 577 en Maintenance manual
GMK7450
16.08.2018
8.8.5 Lubricating the locking of turntable
Grease, spare
parts, tools
–Brush.
Prerequisites – The truck crane must be level and in on-road mode;
à Operating manual.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
– The turntable must be at one of the locking points (0° and 180°).
Greasing
• Familiarize yourself with the operation of the turntable locking and
observe the safety instructions;
à Operating manual.
• Grease the lubricating points (1) and (2) with
the brush.
M 12
Lubricating
grease
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
