Manitowoc GROVE GMK7450 User Manual

Maintenance work on the carrier
7.8 Axle lines
7 - 62 3 302 577 en Maintenance manual
GMK7450
16.08.2018
7.8.6 Lubricating the drive shafts in the axle lines
H
Check all drive shafts to see if they have grease nipples.
drive shafts with grease nipples must be serviced, drive shafts without
grease nipples are m
aintenance-free.
Grease, spare
parts, tools
– Grease gun from the tool set.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspection
pi
t.
–
The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
– The wheels must be turned as far as they will go, so that the lubricating
nipples on the sides of the f
inal drives are more easily accessible.
Greasing
Drive shafts (2) are fitted only to the 14
x 8 x 14
drive.
• Check which drive shafts (1) and (2) have
lubricating nipples (3).
• Clean the grease nipples (3).
• Inject grease into the grease nipples until
grease escapes from the bearing points. Do
not inject grease with excessive force, other-
wise the lip seals may be damaged.
• Remove any grease that has escaped.
M 1
Lubricating
grease
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
