Manitowoc GROVE GMK7450 - Oil Filters 1 and 2 - Cleaning the Magnetic Rod

Maintenance work on the superstructure
8.10 Hydraulic system
8 - 72 3 302 577 en Maintenance manual
GMK7450
16.08.2018
8.10.5 Oil filters 1 and 2 – cleaning the magnetic rod
Spare parts and
tools
– Receptacle, approx. 5 l (1.5 gal);
à P. 2 - 4.
Prerequisites – The truck crane must be standing on an even surface.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
M 3
Designation Quantity GROVE part no.
For oil filter 1:
Filter 1 03325700
Packing set 1 03135853
For oil filter 2:
Filter 1 03317083
Seal (O-ring) 1 01372280
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
