Maintenance work on the superstructure
8.2 Symbols for maintenance work
16.08.2018
Maintenance manual 3 302 577 en 8 - 11
GMK7450
8.2 Symbols for maintenance work
• Check the following lamps and symbols on the side panel and ECOS dis-
play on a daily basis before you start work.
On the side panel If one of the lamps on the side panel is lit in the driver's cab you must carry
out the corresponding mai
ntenance work:
– Engine malfunction;
à P. 8 - 13,
– Air filter;
à P. 8 - 16,
– Engine coolant level (temperature display);
à P. 8 - 17,
– AdBlue system; à P. 8 - 36.
