Manitowoc GROVE GMK7450 - Central Lubrication System; Checking the Filling Level

Maintenance work on the carrier
7.15 Central lubrication system
16.08.2018
Maintenance manual 3 302 577 en 7 - 103
GMK7450
7.15 Central lubrication system
The central lubrication system supplies the steering lever on the first, sec-
ond and third axle lines.
7.15.1 Checking the filling level
Grease, spare
parts, tools
– Filling pump from the tool set.
Prerequisites – The parking brake must be applied.
Checking the fill-
ing level
• Check the level in the grease container (1).
The filling level must be near the max.
marking.
If it is below the min. marking, the level is
too low.
If the level is too low
• Add more grease; à P. 7 - 104.
s
W
Lubricating
grease
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
