Maintenance work on the superstructure
8.4 Fuel system
16.08.2018
Maintenance manual 3 302 577 en 8 - 29
GMK7450
8.4.2 Replacing fuel filter 1
Spare parts and
tools
– Receptacle, approx. 5 l (1.5 gal);
à P. 2 - 4.
Prerequisites – The truck crane must be level.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
– If the fuel is dirty: Reduce the maintenance interval.
Changing
• Place a receptacle underneath the filter.
• Close the valve – lever (2) at right angles to
the line.
• Open the screw (1) and the valve (3) and
drain the consumable.
s
M 6
Designation Quantity GROVE part no.
Filter 1 04182148
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable recept
acles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
