Manitowoc GROVE GMK7450 User Manual

Maintenance work on the superstructure
8.14 Central lubrication system
16.08.2018
Maintenance manual 3 302 577 en 8 - 113
GMK7450
8.14 Central lubrication system
8.14.1 Checking the filling level
The maintenance of the pump (1) is the same
as the maintenance on the carrier;
à Central
lubrication system
, P. 7 - 103.
Connected lubricating points
– Ma
in hoist drum,
– Slewing bearing,
– Telescopic boom – pivot pins,
– Derricking cylinder – pivot pins.
Lubricating points not connected
– Auxiliary hoist drum;
à P. 8 - 45.
W
