Manitowoc GROVE GMK7450 User Manual

Maintenance work on the superstructure
8.7 Slewing gear
8 - 52 3 302 577 en Maintenance manual
GMK7450
16.08.2018
8.7.4 Changing the oil/checking the oil
•
Also adhere to the à Run-in regulations, P. 4 - 1.
Oil, spare parts,
tools
– Receptacle, approx. 5 l (1.5 gal);
à P. 2 - 4.
Prerequisites – The truck crane must be level and in on-road mode;
à Operating manual.
– The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
Changing the oil
• Always change the oil in all slewing gears.
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
0.9 (0.24)
for each
sle
wing gear
C - LPF MIL-L 2
105 B
API-GL-4/5
Viscosity:
SAE 75 W-90 EP
I
SO - VG 220
02313611
Synthetic oil; do
not mix this with
mineral-based
oils!
Designation Quantity GROVE part no.
Gasket 10 x 14 Cu DIN 7603 3 00117125
Gasket 14 x 20 Cu DIN 7603 3 00117132
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
