Manitowoc GROVE GMK7450 - Lubricating the Auxiliary Hoist

Maintenance work on the superstructure
8.6 Hoists
16.08.2018
Maintenance manual 3 302 577 en 8 - 45
GMK7450
8.6.4 Lubricating the auxiliary hoist
Grease, spare
parts, tools
– Grease gun from the tool set.
Prerequisites – The engine must not be running and must be secured against unauthor-
ised use;
à P. 2 - 3.
Greasing
• Clean the lubricating nipple (1) and lubricate
the hoist at the lubricating nipple.
• Remove any grease that has escaped.
M 6
Lubricating
grease
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
S
Risk of damage to the auxiliary hoist!
The auxiliary hoist drum bearing is not automatically lubricated by the
cen-
tralised lubrication pump on the turntable.
Lubricate the auxiliary hoist drum bearing with the grease gun at the lubri-
cating nipple.
